ANENJI ANJ-6200W-48PL-WIFI is a 6.2 kW (6200 W) 48 V hybrid solar inverter with Wi—Fi support and the possibility of parallel operation (up to 12 units in one system, including three-phase). It includes the functions of an inverter, an MRRT solar controller, and a battery charger.

, Main features

Hybrid operation: combines an inverter, an MRRT controller and a charger.

Parallel connection: up to 12 inverters in one system (single- or three-phase).

Wi-Fi monitoring: support for the mobile app and web cabinet.

Pure sine wave: Suitable for all household and office appliances.

120A MPPT controller: works with solar panels at a voltage from 60 to 500 V DC.

Battery-free operation: Can be used directly from solar panels.

Support for LiFePO4 and lead-acid batteries, activation of lithium batteries.

Different priority modes: UTL, SOL, SBU, SUB (network/solar/battery).

Interfaces: RS232, RS485, Wi-Fi, GPRS option.

Protection and reliability: Removable dust cover, protection against overheating, short circuit and overload.

, Technical specifications

Parametervalue

Rated power 6.2 kW

Output current 120 A

Output voltage 230V ±5%, pure sine wave

Mains input voltage 170-280 V (PC), 90-280 V (household appliances)

MPPT60–500V DC range

Max. battery voltage up to ~61 V (overcharge protection)

Intermittent power (peak)6 500 VA

Efficiency to 98 %

Switching time 10 ms (PC), 20 ms (household appliances)

Operating temperature−10 °C ... +55 °C

Humidity 5–95% non-condensing

Dimensions 438 × 295 × 105 mm

Weight: 9 kg
