The ANENJI ANJ-4000W-24V-WIFI inverter is a hybrid device that combines the functions of an inverter, a solar charger and a battery charger. It is designed for autonomous and networked power supply systems such as houses, cottages, campers and boats.

, User 's Guide

For detailed information about setting up and operating the inverter, you can download the user's manual at the following link: 4000W pdf

Do you also need a battery? Click here:

ANENJI, 100Ah capacity, 24 V

, Main features

Model: ANJ-4000W-24V-WIFI

Rated power: 4000W

Peak power: 7000 Watts

Output voltage: 220/230 V AC

Output waveform: Pure Sine wave

Power factor: 1.0

Battery input voltage: 24 V

Maximum battery charge current: 100 A

MPPT Voltage Range: 60-500 V DC

Maximum input power from solar panels: 4000 watts

Efficiency: Up to 93%

Battery switching time: 10 ms

Supported battery types: Li-ion, Lifepo₄, lead-acid

Communication interfaces: RS232, RS485, Wi-Fi

Display: LCD display for setting and monitoring

Dimensions: 358 × 295 × 100 mm

Weight: 7 kgapji.com+4anenji.net+4anenji.cn+4

🛡️ Protection and functions

Protection against: overload, overheating, short circuit, reverse polarity

UPS function: Provides uninterrupted power when the network is disconnected

Cooling: Active (fans)

Operating temperature: -10 to +55 °C

, Complete set and additional options

Package Contents: Inverter, User manual

Additionally: The ability to connect a Wi-Fi module for remote monitoring
